INTRODUCTION
The Combined Sewer Truck is intended for vacuum cleaning of cesspools and transportation of fecal liquids to disposal areas. Special equipment must consist of the tank, driven vacuum pump, signal-safety device, receiving manhole with suction hose, control valves on the pipeline, platforms, and additional electrical equipment. Filling of the tank is carried out under the impact of vacuum which is produced by the vacuum pump, tank gravity discharge, or air pressure from the vacuum pump.
The Combined Sewer Truck works by the principle of trusting and breaking the effects of high pressured water for opening any blockage shutting the sewer system and after destroying the blockage; all the remaining sludge, wastewater, and half solid waste is collected inside the sludge tank by the strong vacuum force created by means of the vacuum pump.
STANDARD FEATURES
l Tank Volume 6000Liters
l HOWO L2W 4×2 Chassis
l ISUZU 116hp Diesel Engine
l Size 5.995×2.09×2.65m
l Sewer Truck Weight 2870kg
l WEILONG Vacuum Pump
l Deep Vertical Suction(depth 8m)
l Qualitied Vacuum Pump
l Automatic Release Valve
l Reliable Safety System
l Operating and maintenance manuals and CDs in the English language
l Automatic Welded Vac tipping tank, water tank truck.
Our Combined Sewer Truck is Available in ( click the following each model to know more details)
l 4CBM Vac Jet Combination Truck
l 8CBM Combined Vacuum Sewer Truck
l 10CBM Combined Sewer Cleaner Truck
l 12CBM Combination Sewer Jetter Truck
l 14CBM Combination Sewer Jetting Truck
l 16CBM Combination Jetting Cleaning Truck
l 18CBM Combo Sewer Jetter Truck
l 20CBM Combo Sewer Cleaning Truck
OPERATION LOADING 6,000 LITERS OF SEWAGE Hydro Vacuum Excavation Units – Handle any soils, liquids, or wet solid waste in any road situation.
HOWO Light-duty Chassis Parameters:
| Weight | Chassis Weight(kg) | 2565 | |
| Loaded(kg) | 4495 | ||
| Towing(kg) | |||
| Measurement | Size | Length(mm) | 5995 |
| Width(mm) | 2150,2250,2350,2498 | ||
| Height(mm) | 2500,2550 | ||
| Wheelbase(mm) | 3160,3280 | ||
| Chassis-Ground(mm) | 210 | ||
| Performance | Max Speed(km/h) | 95 | |
| Suggestion Speed(km/h) | 50-70 | ||
| Climb(%) | 25 | ||
| Turning Radius(m) | 13.4,13.8 | ||
