Combined Vacuum Sewer Truck is also called Combined Sewer Cleaner Truck, functionally with high-pressure better cleaning and vacuum suction for sewage sewer cleaning truck. The truck is consist of a debris tank body with a vacuum pump system, a water tank body with a water pump system, a flushing hose, nozzles, and a suction boom system with a discharge drain hose.
As the sewer cleaning vacuum trucks manufacturers, we can supply 4-20 tons combined vacuum sewer trucks and these kinds of trucks for sale are always in the leading position in this field around china market.
Our Jet-Vac Trucks are Available in:
● 4CBM Vac Jet Combination Truck
● 6CBM Combination Sewer Cleaning Truck
● 8CBM Combined Vacuum Sewer Truck
● 10CBM Combined Sewer Cleaner Truck
● 12CBM Combination Sewer Jetter Truck
● 14CBM Combination Sewer Jetting Truck
● 16CBM Combination Jetting Cleaning Truck
● 18CBM Combo Sewer Jetter Truck
● 20CBM Combo Sewer Cleaning Truck
ORDER YOUR TANKS FROM CSCTRUCK
● SUPER SV PLANT: We are the market leader in the production of fuel tanks in China.
● PRODUCTIVITY: 670,000Sqm facility, 1,500 workers, 28 assembly lines, the yearly output of 20000 units of special trucks, and 10000 sets of construction ensure your bulk delivery.
● EURO TECHNOLOGY: Applied 150 pcs of Patents. Advanced engineering made our tank trucks well reputation.
● CERTIFICATED MATERIALS: High-quality tanks in SS, aluminum, or steel with durability.
● QUALITY CONTROL: GB/T19001-2008, ISO9001:2008 Quality Management System Standard certificated.
● CUSTOMIZED: We can make whatever specialized feature you need for your next tanker.
● VARIETIES: We are engaged in providing a rich choice of options for your fleet.
● RELIABILITY: Effective performance and also low maintenance.
● PROFESSIONAL: Our experienced engineering team, will support you in finding the best logistical solution.
Features & Benefits
Tipping Tank:
● Sludge Tank (Thickness 6mm steel ) Volume: 4000 lt. Water Tanker(Thickness 5mm steel ) 4000L
● Combination wash /Hydro Vac system
● WEILONG Vacuum pump, TONGJIE Plunger Pump (16-19Mpa, 8m3/h)
● 60M hose, 1800N, 19mm diameter, Reel speed at 0-25m/min
● Water flushing width 2.5m-3.5m, pressure 9Mpa, 120L/min, Cleaning width > 16m, Water Gun Range >38m.
● Sludge Tanker,
● High capacity cyclone with full opening lid.
● 2” quick-acting brass drain valve (heated) mounted on the front head.
● 2-4” air open/spring close valve. Camlock fitings.1-6” discharge valve.
● Hydraulic full opening rear door assembly with 6 heavy-duty wing clamps.
● Double-acting hydraulic cylinder.
● 4” pipe overturn protection and gussets.
● 1-6” exhaust and 1-6” intake
● Full-length hydraulic dump subframe
● Hydraulic reservoir, hydraulic oil filter, and sight glass.
● Spool valve control of rear door, hoist, and vibrator. Separate controls for the wash pump(inside the cabinet).
● Hydraulic vibrator assembly on the bottom of the tank.
● Full-length steel checker plate fenders,
● Tubular handrails, numbered placards, static ground cable, toolbox complete with rain lip.
● 6” or 8” suction boom assembly with 4’ extension-hydraulic powered functions and extension.
● Electronic /Hydraulic pendant controls with 25’ of cable. Boom fully extends to 16’.
● 10pcs of different size Nozzles
● Color as customer specifications.
● Many more options are available on request.
Accessories:
● Hose trays: 1 unit with 8-meter
● Access ladder: 200 kg lifting capacity
● Mudguard: Polyethylene, made for the rear wheels of the truck
● Suction hoses: Total of 16 meters, high endurance suction hoses with the following configuration.
PICK UP A CHASSIS
We offer oil tank trucks on a variety of chassis including ISUZU, HINO, UD, JAC, SINOTRUK, SHACMAN, BEIBEN, and DONGFENG, available on any commercial chassis..
*Please scroll down to see this Municipal Vacuum Tank Truck chassis inventory, you may optional choose above different brand of chassis for one of your tanks, or need a new tank for one of your truck chassis for mounting this Municipal Vacuum Tank. There is the one you need.
