The FAW 10 ton road sprinkler truck, manufactured by CSCTRUCK, is a reliable and durable vehicle that is designed to effectively water roads, highways, and other urban areas. Here is a detailed description of its features and specifications.
Chassis:
This road sprinkler truck is built on a sturdy chassis that measures 8,250mm in length, 2,500mm in width, and 2,850mm in height. It has a gross vehicle weight (GVW) of 18,000kg and a curb weight of 9,500kg. The wheelbase of the truck is 4,200mm, and it is equipped with 6.5/11.5T front and rear axles. The truck runs on 10.00R20 tires, which are 6+1 in number.
Engine:
The FAW 10 ton road sprinkler truck is powered by a diesel engine that delivers 220 horsepower. The engine is manufactured by YUCHAI and is model YC6J220-30. It is compliant with the Euro 3 emission standards.
Transmission:
The truck is equipped with a manual transmission system that has 8 forward gears and 2 reverse gears. The transmission system is manufactured by FAW and is model CA8TAX090M.
Cabin: The truck has a comfortable and spacious cabin that can accommodate up to 3 passengers. The driving position is on the left-hand or right-hand side, depending on the market. The cabin is made of steel construction and has a single-row, flat design.
Body System:
The tanker of the FAW 10 ton road sprinkler truck has a capacity of 10,000L. It is made of high-quality stainless steel 304 and has a thickness of 6mm. The shape of the tanker is designed to ensure maximum coverage during spraying operations.
Performance:
The truck has an impressive spraying width of more than 14m and a canon range of more than 35m. It can also suction water from a height of more than 7m, and the full tank suction time is less than 15 minutes. These features make the FAW 10 ton road sprinkler truck an efficient and reliable choice for watering urban areas.
Equipment:
The sprinkler pump of the truck is made of stainless steel and is self-priming. It has a flow rate of 60m³/h and a lift height of 90m. The self-priming height of the pump is 7m. Other parts of the truck’s equipment include a self-flow valve, a fire joint, and two water pipes.
In summary, the FAW 10 ton road sprinkler truck is a high-performance and reliable vehicle that is designed to meet the needs of urban watering. Its powerful engine, durable chassis, and efficient equipment make it an ideal choice for municipalities and contractors who require a dependable and efficient road sprinkler truck.
| Chassis | FAW |
| Size | 8,250×2,500×2,850(mm) |
| GVW/Curb Weight | 18,000kg/9,500kg |
| Wheelbase | 4,200mm |
| Front/Rear Axle | 6.5/11.5T |
| Tire | 10.00R20 6+1 tires |
| Engine | |
| Type | Diesel |
| Make/Model | YUCHAI/YC6J220-30/220hp/euro 3 |
| Transmission | |
| Make/Model | FAW/CA8TAX090M |
| Gears | 8F+2R |
| Operation | Manual |
| Cabin | |
| Driving | FAW J6L 4×2 Day Cab, Left/Right-hand Drive |
| Type | Steel construction, Single Row, Flat |
| Passenger No. | 3 |
| Body System | |
| Tanker Capacity | 10,000L |
| Shape | |
| Material | Stainless steel 304 |
| Thickness | Tank Body 6mm |
| Performance | |
| Spraying Width(m) | ≥14m |
| Canon Range(m) | ≥35m |
| Suction Height | >7m |
| Full Tank Suction Time | <15 minutes |
| Equipment | |
| Sprinkler Pump | Front flushing, side spraying, rear sprinkling nozzle, and platform with water cannon and gun.
The water cannon can be rotated 360 degrees. The water flow can be adjusted to heavy, medium, light rain, drizzle, and mist. |
| Type | Stainless steel self-priming sprinkler pump |
| Flow Rate | 60m³/h |
| Lift Height | 90m |
| Self-priming Height | 7m |
| Other Parts | |
| Include | Self-flow valve 1pc; Fire joint 1pc; Water pipe 2pcs |
