| Chassis | |
| Size | 8,200×2,500×3,450mm |
| GVW/Curb Weight | 18,000/8,500kg |
| Wheelbase | 4600mm |
| Front/Rear Axle | 5T/13T |
| Tire | 11.00R20, 6+1 tires |
| Engine | |
| Type | Diesel |
| Make/Model | YUCHAI/YC6A240-33/240HP/Euro 3 |
| Transmission | |
| Make/Model | FAST/8JS |
| Gears | 8F+1R |
| Operation | Manual |
| Cabin | |
| Driving | FOTON AUMAN 4×2 Day Cab, Right-hand Drive |
| Type | Steel construction, Single Row, Flat |
| Passenger No. | 3 |
| Garbage Container | |
| Capacity | 12 CBM |
| Container Material | High tensile wear-resistant carbon steel |
| Thickness | Side and top 4mm, Bottom 4mm |
| Type | Underground and aboveground types are optional |
| Include | 1 PTO drives the hydraulic system, two balance valves, two hydraulic cylinders with a lifting arm and landing leg, and one unloading container locking pins. |
| Options | Stainless steel container material;
Sealed cover for the container; A truck with several containers |
| Loading Time | 30s |
| Unloading Time | 50s |
