FOTON 3000 Liter Septic Cleaner Truck Body

FOTON 3000 Liter Septic Cleaner Truck

3,000Liters Water Tank
Italy High Pressure Jetting Pump
60-120meters Jetting Hoses
Various Types of Jetting Nozzles
Hose Reel Rotated and speed adjusted
FOTON Chassis Truck Adopted

Send An Inquiry

Categories: Sewer Cleaner Truck, Sewer Truck

BRIEFS

The FOTON 3000 Liter Septic Cleaner Truck is designed for efficient waste collection and transportation. It’s equipped with a durable chassis and specialized features for effective cleaning and maintenance.

FEATURES

Chassis
- Size: 5,9952,0302,380 (mm)
- GVW/Curb Weight: 7,300/4,055kg
- Wheelbase: 3360mm
- Front/Rear Axle: 2.2T/5T
- Tire: 7.00R16, 6+1 tires
Engine & Transmission
- Type: Diesel
- Make/Model: FOTON /BJ493ZLQV1/ 108HP/ Euro 3
- Transmission: Getrag/JC5-28, 5F+1R, Manual
Cabin
- Driving: FOTON 4×2, Left/Right Hand Drive
- Type: Steel construction, Single Row, Flat
- Passenger No.: 3
Upper Body
- Water Tank: 3,000Lt, mild steel, manhole on top
- Tank-Chassis Mounting: Mounted on the auxiliary frame for chassis connection
- Level Gauge: Liquid level gauge installed
- Water Tank Filling: Gravity or hydrant fill options
- Water Pump: High-pressure jetting pump, Pratissoli KF36, 160bar
- Canal Hose: 60-120 meters optional
- Rear Hose Reel: Hydraulic for rotation, winding & rewinding
- Jetting Nozzles: 3-4pcs of various jetting nozzles

SPECIFICATIONS:

Chassis
Size	5,9952,0302,380 (mm)
GVW/Curb Weight	7,300/4,055kg
Wheelbase	3360mm
Front/Rear Axle	2.2T/5T
Tire	7.00R16, 6+1 tires
Engine
Type	Diesel
Make/Model	FOTON /BJ493ZLQV1/ 108HP/ Euro 3
Transmission
Model	Getrag/JC5-28
Gears	5F+1R
Operation	Manual
Cabin
Driving	FOTON 4×2, Left/Right Hand Drive
Type	Steel construction, Single Row, Flat
Passenger No.	3
Upper Body
Water Tank	3,000Lt, mild steel, manhole on top of water tank
Tank-Chassis Mounting	The water tank mounted on the auxiliary frame to connect with the chassis frame
Level Gauge	Liquid level gauge installed on water tank
Water Tank Filling	Can be filled by gravity or hydrant
Water Pump	High-pressure jetting pump, Pratissoli KF36, 160bar
Canal Hose	60-120meters optional
Rear Hose Reel	Rotated and winding & rewinding by hydraulic
Jetting Nozzles	3-4pcs various jetting nozzles

Related Municipal Truck Knowledge and News:

Certification	CCC, CE, ISO14001:2015, ISO45001∶2018, ISO9000, ISO9001:2015, RoHS
Chassis Truck	FOTON
Color	Customized Color, Green, Grey, White, Yellow
Country of Origin	Made in China
Customized	Yes
Delivery Time	20 Days, 245hp, 30 Days, 50 Days, 60 Days
Drive Mode	4×2
Emission Standard	Euro II, Euro III, Euro IV, Euro V, Euro VI
Factory Address	NO.9, Jiliang Avenue, Suizhou Economic Dvpt Zone Suizhou (441300 ) Hubei China
Fuel Type	Diesel
Main Markets	Africa, Eastern Asia, Mid East, North America, Oceania, South America, Southeast Asia
Packaging Details	Waxed
R&D Capacity	ODM, OEM, Own Brand(CSCTRUCK)
