HOWO Rear Loader Truck is to empty containers with hydraulic devices or winch. Waste inside of garbage truck is pressed which increases the efficiency of using this type of equipment. It is intended to handle household and commercial refuse as well as compactable industrial waste.
HOWO Rear Loader Truck is designed with one-piece, curved shell body side construction for superior strength and streamlined appearance. The optional back pressure valve is to increase the pressure capacity of the dozer. The density of garbage can reach 0.8-0.85Kg/m3, which can increase the loading capacity by about 30% and greatly improve the use efficiency. Double control system easy to operate.
features
Body Unit Only without ChassisMaterials
-Rear loader body is produced of high-strength steel Q235, 4-6 mm thick
-The bottom of the container is cone-shaped (for the effective flow of caustic filtrate from the garbage in order to prolong the life of the body).
-Hopper is made of high-strength steel, 6mm thick.
Hydraulics
-High-quality cylinders are used.
-All valves are with electro-hydraulic control.
-Maximum system pressure is 250 bar.
-Hydraulic flow: 80 l/min, lifting device 40 l/min.
-In standard up to 95% of hydraulic hoses, which could be damaged, are protected with metal casing.
Loading of Waste
-Available lift standard 120/240/770 and 1100 liter. steel and plastic containers.
-Lifting capacity: 500 kg.
-Lift cycle time: 10~15 sec.
-Time of unloading of 6m3 container 3 min.
Standard Accessories
– Foldable Operator Steps on both sides
– Hand grips, hand bars on both sides for operators
– One Nos Working light in a suitable place of the tailgate
– One Nos Rotating beacon in a tailgate
– Operating sticker’s in necessary places.
– Rearview camera located on tailgate and 7” screen on truck cab.
– Operating and maintenance manuals in English
– Side guards where applicable
Optional Accessories
-Winch system and shaking mechanism for tipping device,
-Additional beacon light on the body and tailgate,
-LED lamps
-Stainless steel or plastic toolboxes.
-Monitor in the cabin and one reversing camera in the tailgate
specification
| Size | 6,590×2,050×2,540mm |
| Gross/ Kerb Mass (kg) | 10995/ 5400 |
| Wheelbase (mm)/ Axis No. | 3360 |
| Driving type | 4*2 LHD |
| Chassis model | SINOTRUK HOWO |
| Tire size | 8.25R16/6+1spare tire |
| Engine | CHAOCHAI,136hp ,Euro 3 |
| Container Capacity | 6CBM |
| Compaction Ratio | 0.6~0.8T/m3 |
| Lifting weight capacity | 750 kg |
| Tailgate Lifting Cycle (s) | 10-15s |
| Compaction Plate Working Cycle (s) | 15-20s |
| Hopper Opening (°) | 67 |
| Container Opening (°) | 48 |
| Steel Material | High corrosion resistance Q235 carbon steel 5-6mm |
| Painting | Metallic Paint |
