features
-High-efficiency centrifugal fan for washing and sweeping. The fan bearing adopts imported FGA bearing, which can prolong the life for 3 years.
-Double suction nozzle in the middle, 6mm thickness material is used for the suction pipe connection, effectively prevent deforamtion caused by the impact of large particles sucked in.
-Original imported high-pressure water pump for washing and sweeping truck, with a rated pressure of 12MPA.
-The sweeping broom is adopts a single oil cylinder to control the lifting and sweeping, with anti-collision and avoidance function.
-Equipped with a 20m high-pressure hose.
-High pressure spray device and front high pressure flushing.
-Adopt the control mode of “display”+controller+CAN bus operation panel, one key to start and turn down.
specification
| Chassis | Size | 5995*2550*3400mm |
| Gross weight | 4495kg | |
| Curb Weight | 2720kg | |
| Wheelbase | 3360kg | |
| Driving type | 4*2 RHD | |
| Chassis model | SINOTRUK HOWO G3W | |
| Tire size | 10.00R20-16PR | |
| Number of Tires | 6+1 | |
| Passengers in cab | 3 | |
| Engine | Engine model | MC04.16-50 |
| Type of fuel | Diesel | |
| Power | 160HP | |
| Max speed | 95Km/h | |
| Emission standard | EURO 5 | |
| Performance | Capacity | 8000L |
| Maximum Cleaning Width | 3.2m | |
| Working Speed | 3~20km/h | |
| High Pressure Water Pump Rated Pressure | 12MPa | |
| High Pressure Water Pump Rated Flow | 100L/min/1450rpm | |
| Maximum cleaning capacity | 65000m²/h |
