ISUZU 12CBM Rear Loader Garbage Truck

Chassis
Size	8785x2465x2810(mm)
GVW/Curb Weight	16,000/10,200kg
Wheelbase	4500mm
Front/Rear Axle	6.3T/13T
Tire	10.00R20, 10+1 tires
Engine
Type	Diesel
Make/Model	ISUZU/4HK1-TC50/205HP/Euro V
Transmission
Make/Model	ISUZU/MLD
Gears	6+1 Gear Numbers
Operation	Manual
Cabin
Driving	ISUZU FTR 4×2 Day Cab, Right Hand Drive
Type	Steel construction, Single Row, Flat
Passenger No.	3
Garbage Container
Capacity	12 CBM
Tank Body Material	High Tensile Carbon Steel
Thickness	Side 4mm, Bottom 5mm
Design	Sealed leakage proof
Working Rotation Speed	1400r/m
Compaction Ratio	1:3- 1:4
Hopper Volume	0.8CBM
Effective volume of bucket	≥0.8cbm
Loading Time	8~10s
Loading Cycle Time	≤40s
Unloading Time	≤45s
Discharge Type	Rear discharging
System Pressure	16MPA
Hydraulic System	Branded oil pump, oil cylinder, valve, gauge, oil tank, pipeline
Control System	Multi-Control

Certification	ISO9001:2015
Chassis Truck	ISUZU
Color	Customized Color
Condition	New
Country of Origin	Made in China
Customized	Yes
Delivery Time	50 Days
Drive Mode	4×2
Emission Standard	Euro V
Fuel Type	Diesel
Intercom	CIF
Main Markets	Africa, Eastern Asia, Mid East, North America, Oceania, South America, Southeast Asia
Packaging Details	Waxed
R&D Capacity	ODM, OEM, Own Brand(CSCTRUCK)
Shipping Vessel	Bulk Shipment, Container Shipment, Flat Rack, FR Container Shipment, RORO Shipment
Steering	LHD
Terms of Payment	T/T
Truck Class	Heavy Duty
Warranty Period	12 Months
