BRIEFS:
Introducing the SAIC 10 Ton Electric Road Sprinkler Truck, a remarkable vehicle designed to revolutionize road maintenance and environmental conservation. This cutting-edge electric truck boasts exceptional performance and efficiency, making it a standout choice for sustainable urban development.
The sprinkler truck is a powerful, eco-friendly solution for road maintenance and urban sustainability, offering exceptional performance, efficient energy consumption, and a comprehensive suite of standard features for enhanced functionality and driver comfort.
FEATURES:
Battery and Electric Motor:
- Battery Manufacturer/Power: Equipped with a high-capacity CATL lithium iron phosphate battery with a robust 314.14kWh capacity.
- Electric Motor (Driving System): Powered by an efficient LVKON 6AMT electric motor that delivers both impressive rated and peak power of 100kW and 185kW, respectively.
- Torque Performance: Offers remarkable torque performance with a rated torque of 750N·m and a peak torque of 1300N·m.
- Energy Density: The power battery system boasts an impressive energy density of 140.7 Wh/kg, ensuring long-lasting and efficient operation.
- Battery Arrangement: Features a piggyback battery arrangement for optimized space utilization and weight distribution.
Performance and Efficiency:
- Driving Range: Provides an estimated driving range of 250 kilometers under comprehensive road conditions, ensuring extended operation without frequent recharging.
- Extended Range: Achieves an impressive 436 kilometers of driving range when maintaining a constant speed of 40km/h.
- Efficient Power Consumption: At a constant speed of 40km/h, the truck consumes a mere 53.16 kWh per 100 kilometers, showcasing exceptional energy efficiency.
Transmission and Axles:
- Gearbox: Equipped with a 6AMT gearbox featuring gear ratios of 6.62/3.73/2.3/1.51/1/0.75, ensuring smooth and versatile operation.
- Axle Ratios: Features an efficient axle ratio of 6.833 for optimized power delivery.
Suspension and Braking:
- Front Suspension: Utilizes a leaf spring setup with nine pieces, providing a balance of comfort and load-bearing capacity.
- Rear Suspension: Features a leaf spring configuration with a total of 11+8 leaf springs to handle varying loads.
- Braking System: Equipped with air brakes, including front disc brakes and rear drum brakes, ensuring reliable stopping power.
- Parking Brake: Employs an air brake system for secure parking.
Safety and Comfort:
- ABS: Standard anti-lock braking system enhances vehicle stability during braking.
- Cruise Control: Offers cruise control for convenient and fuel-efficient highway driving.
- In-Cabin Amenities: Provides standard amenities such as a radio with USB support, an LCD instrument display system (driving computer), air conditioning, and an adjustable multi-function steering wheel.
- Safety Features: Includes safety features like brake energy recovery, pedestrian and turning reminders, and a high-voltage power supply for enhanced safety.
Charging and Power Management:
- DC Charging: Equipped with DC charging capabilities for rapid battery replenishment.
- Battery Thermo Management: Ensures efficient battery temperature management.
- Voltage System: Operates on a single-wire, 24V electrical system with negative grounding.
- Alternator and Starter Motor: Features a 1540W alternator and a 7.5kW starter motor for reliable performance.
Exterior Lighting:
- Front Lamp Height Adjustment: Offers electrically adjustable front lamps for optimal visibility.
- Front Lamp Type: Equipped with halogen front lamps for dependable illumination.
The SAIC 10 Ton Electric Road Sprinkler Truck combines high-performance electric propulsion with a host of advanced features to deliver efficient, eco-friendly road maintenance and environmental conservation solutions. This vehicle is designed for both extended range and efficiency, making it an excellent choice for sustainable urban development and road maintenance operations.
SPECIFICATIONS:
| Specification | Details |
|---|---|
| Model | EC501-52D18 |
| Wheelbase (mm) | 5200 |
| Cabin Type | Single Cabin |
| Seating Capacity | 3 |
| Battery (Manufacturer/Power) | CATL 314.14kWh |
| Motor (Driving System) | LVKON 6AMT |
| Rated/Peak Power (KW) | 100/185 |
| Rated/Peak Torque (N·m) | 750/1300 |
| Tire Distribution | Rear Double Tire |
| Tire Model | 295/80 R22.5 18PR (Tubeless) |
| Driving Type | Motor Middle-Mounted, Rear-Wheel Drive |
| Battery Arrangement Form | Piggyback |
| Battery Material | Lithium Iron Phosphate Battery |
| Power Battery System Weight (kg) | 2150 |
| Energy Density of Power Battery System (Wh/kg) | 140.7 |
| Rated Voltage (V) | 580 |
| Estimating Charging Time (h) | 2.17 |
| Mass | |
| – GVW (Kg) | 18000 |
| – CVW (Kg) | 7011 (Chassis) |
| – Full Load (Front/Rear) (T) | 7.0T/11.0T |
| – Load Distribution of No-Load (Front/Rear) (T) | 4.4T/2.6T |
| Vehicle Size | |
| – Length x Width x Height (mm) | 8600×2500×2535 |
| – Tank Size (Width x Height x Length) (mm) | 2200×1240×4700 |
| – Front/Rear Overhang (mm) | 1230/2150 |
| – Front/Rear Tread (mm) | 1860/1865 |
| – Frame (mm) | 250807+4 |
| Performance Parameters | |
| – Driving Range (Comprehensive Road Condition, km) | 250 |
| – Driving Range (Constant Speed of 40km/h) | 436 |
| – Power Consumption (kWh/100km) (Constant Speed of 40km/h) | 53.16 |
| Gearbox | |
| – Model | 6AMT |
| – Gear Ratios | 6.62/3.73/2.3/1.51/1/0.75 |
| System Components | |
| – Axle Ratios | 6.833 |
| – Steering Form and Structure | Electro-Hydraulic Steering |
| – Front Suspension | Leaf Spring (9 PCS) |
| – Rear Suspension | Leaf Spring (11+8 PCS) |
| – Brake | Air Braking, Front Disc/Rear Drum |
| – Parking Brake | Air Brake |
| Configuration | |
| – ABS | Standard |
| – Cruise Control | Standard |
| – Radio+USB | Standard |
| – LCD Instrument Display System (Driving Computer) | Standard |
| – AC | Standard |
| – Brake Energy Recovery | Standard |
| – Pedestrian Reminder | Standard |
| – Turning Reminder | Standard |
| – High Voltage Power Supply | Standard |
| – DC Charging | Standard |
| – Adjustable Multi-Function Steering Wheel | Standard |
| – Front Lamp Height Adjustable (Electric) | Standard |
| – Halogen Front Lamp | Standard |
